Switch seamlessly from wheel alignment to ADAS calibration with a single click. No repeated setup is required, improving workflow efficiency and reducing service time.
High-definition digital targets display real-time calibration and wheel alignment information. Their space-saving design provides an intuitive and efficient operating experience.
Automatically captures centering, parallelism, and height measurements without manual input. Dynamic visual guidance ensures fast and accurate adjustments.
Wirelessly projects wheel alignment and ADAS calibration data from the tablet to a large display, enabling real-time monitoring and a unified user interface.
Optimized ADAS calibration software with clear, step-by-step instructions and illustrated guidance reduces training time and simplifies operation for technicians.
Supports calibration and wheel alignment data for over 95% of global ADAS-equipped vehicles. The continuously updated database ensures compatibility with leading automotive brands.
Generate professional calibration and wheel alignment reports instantly. Reports can be shared electronically and archived digitally for improved documentation and customer service.
| Functions | Description | ✓ |
|---|---|---|
| Wheel alignment measurement | Supports standard and quick measurement modes. Measures key parameters including toe-in, camber, caster, kingpin inclination, thrust angle, wheelbase, track width, axle offset, wheel offset, diagonal, and center offset. | ✓ |
| ADAS intelligent calibration | Digital targets switch automatically with no physical target installation or storage required, enabling faster and more efficient ADAS calibration. | ✓ |
| Centering, parallelism, and height adjustment | The laser system automatically aligns centering and parallelism while beam height is automatically detected and adjusted. Supports manual or electric lifting, with bubble level assistance for precise leveling. | ✓ |
| Intelligent terminal integration | The ST13 smart connection terminal wirelessly projects measurement and calibration data to a 75-inch display, providing real-time monitoring throughout the calibration process. | ✓ |
| Vehicle database | Includes wheel alignment data for over 50,000 vehicle models and supports user-defined databases. Covers calibration for more than 95% of ADAS-equipped vehicles worldwide with continuous database updates. | ✓ |
| Test Report | Generates professional test reports, supports before-and-after adjustment comparisons, and allows convenient report sharing. | ✓ |
Looking for the right automotive workshop equipment? Whether you need product recommendations, a customized quotation, or technical guidance, our team is here to help. Contact us today, and we’ll provide the right solution for your business.
| Parameters | |||
|---|---|---|---|
| Toe-in | ±20° | Clarity | 2160p |
| Camber | ±10° | Screen Size / Screen Ratio | 75 inches / 16:9 Widescreen |
| Caster | ±10° | Resolution | 3840 × 2160 |
| Kingpin Inclination | ±20° | Operating System | Android |
| Maximum Steering Angle | ±35° | Network Connection Method | Wi-Fi |
| Wheelbase | 1940–4600 mm | Memory | 1.5G + 8G |
| Track Width | 1290–1900 mm | Power Supply Voltage | 110–240V |
| Wheel Hub Diameter (Four-Point Wheel Hub Clamp) | 275–640 mm | Overall Power | 138W |
| Tire Diameter (Three-Point Tire Clamp) | 470–1100 mm | Standby Power | <0.5W |
