Features a patented lever-less clamping system with alloy steel locking nuts, providing fast wheel locking while protecting alloy rims from scratches and damage.
Equipped with a patented hand-operated bead breaker featuring vertical pressure assistance and damping technology, making tire bead separation smoother and easier.
The innovative tire mounting head eliminates the need for traditional tire levers, reducing effort while speeding up tire removal and installation, especially for low-profile tires.
Uses a fully automatic swing arm and sliding roller system to assist tire mounting and demounting, improving efficiency and minimizing the risk of tire damage.
Built with a reinforced mechanical arm, wear-resistant sliding components, and precision-ground square tubing to ensure smooth movement, durability, and long service life.
The six-bar linkage design provides balanced force distribution, making tire pressing operations smoother, faster, and less physically demanding.
Includes an explosion-proof oil mist device with excellent pressure resistance, delivering enhanced operational safety during tire inflation.
Supports an optional reverse clamping fixture for handling specialized wheels and improving versatility across different tire service applications.
Looking for the right automotive workshop equipment? Whether you need product recommendations, a customized quotation, or technical guidance, our team is here to help. Contact us today, and we’ll provide the right solution for your business.
| Parameters | |||
|---|---|---|---|
| Rim Diameter Range | 12"–28" (Turntable-Free) | Power Supply | 110V / 220V / 380V |
| Maximum Tire Width | 14" (355 mm) | Motor Power | 0.75 / 1.1 kW |
| Maximum Tire Diameter | 44" (1120 mm) | Net / Gross Weight | 356 kg / 412 kg |
| Working Air Pressure | 8–10 bar | Package Dimensions | 1170 × 1120 × 1850 mm |
| Operating Speed | 7 rpm | Container Loading Quantity | 20GP: 10 pcs | 40HQ: 20 pcs |
| Bead Breaker Force | 2500 kgf | ||
