Includes more than 900 electric compressor drive data entries, covering leading vehicle brands with continuous database updates for newer models.
Supports electric compressor circuit testing and mechanical function testing, including pressure holding, for reliable maintenance and performance evaluation.
Provides electric compressor fault-code repair guidance, real-time online maintenance support, and access to circuit diagrams for faster and more accurate troubleshooting.
| Functions | Description | ✓ |
|---|---|---|
| Comprehensive Airtightness Testing | Performs electric compressor circuit testing and mechanical airtightness testing, including pressure build-up and pressure holding, to improve maintenance efficiency. | ✓ |
| Repair Guidance | Provides detailed repair guidance for compressor fault codes with real-time access to maintenance cases and circuit diagrams. | ✓ |
| Tablet Wireless Connection | Supports wireless tablet connectivity for remote operation, ideal when the device is installed in hard-to-reach locations. | ✓ |
| Real-Time Process Visualization | Displays the complete testing process, including pressurization, pressure holding, venting, and other operating stages in real time. | ✓ |
| One-Click Intelligent Testing | Automatically completes pressurization, stabilization, testing, and gas release, providing a fully automated and intelligent testing workflow. | ✓ |
| Historical Data Management & Sharing | Automatically saves test records and supports sharing PDF reports via Bluetooth, email, or QR code for easy documentation. | ✓ |
| Convenient Online Upgrades | Supports online software updates without requiring USB-based local upgrades, ensuring the latest features and maintenance data. | ✓ |
Looking for the right automotive workshop equipment? Whether you need product recommendations, a customized quotation, or technical guidance, our team is here to help. Contact us today, and we’ll provide the right solution for your business.
| Parameters | |||
|---|---|---|---|
| Input Voltage | AC 90–264V, 50–60Hz | Low-Voltage Output Current | 2A |
| Maximum Input Power | 7 kW | Gas Tank Capacity | 3 L |
| High-Voltage Output Voltage | DC 50–750V | Equipment Air Pressure | 12 kgf/cm² |
| High-Voltage Output Current | 20A Max | Communication Methods | Wi-Fi + Bluetooth |
| Low-Voltage Output Voltage | DC 12V / 24V | Protection Function | 0–40A Adjustable Circuit Breaker |
| Work Environment | Operating Temperature | -10°C ~ 50°C | |
| Storage Temperature | -20°C ~ 70°C | ||
| Operating Humidity | 20%–90% RH | ||
| Storage Humidity | 10%–90% RH | ||
