Combines high-voltage vehicle charging, battery pack charging, and low-voltage power supply for automotive components in a single system, providing flexible compatibility for EV maintenance.
High-voltage and low-voltage modules operate independently and feature multiple built-in protection mechanisms to ensure stable, reliable, and safe operation.
Equipped with foldable casters for easy movement around the workshop while allowing stable placement when used as a desktop or service station device.
Features a 10-inch HD touchscreen with an intuitive interface, delivering smooth operation, clear data visualization, and an improved user experience.
| Functions | Description | ✓ |
|---|---|---|
| Low-Voltage Output | Provides a stable 12V DC output with up to 5A constant current, suitable for powering and testing low-voltage automotive components. | ✓ |
| High-Voltage Output | Supports adjustable 50–1000V DC output with configurable voltage and current settings through the on-screen interface. | ✓ |
| Vehicle Charging | Supports full-vehicle charging through a standard fast-charging connector, making it ideal for maintenance, inspection, and emergency service applications. | ✓ |
| Battery Pack Blind Charging | Enables direct charging of battery packs without relying on the BMS, providing safe and efficient battery recovery and maintenance. | ✓ |
| BMS Data Acquisition | Reads key battery parameters including SOC, voltage, current, temperature, and cell status for battery diagnostics and health assessment. | ✓ |
| Multiple Safety Protections | Integrates overvoltage, undervoltage, overtemperature, short-circuit, reverse polarity, and current-limiting protection to ensure safe and reliable operation. | ✓ |
Looking for the right automotive workshop equipment? Whether you need product recommendations, a customized quotation, or technical guidance, our team is here to help. Contact us today, and we’ll provide the right solution for your business.
| Parameters | |||
|---|---|---|---|
| Charging Voltage Range | 50–1000V | High-Voltage Power Supply Current | 0.5–20A |
| Charging Current | 67A Max | Power Input | AC 274–487V, 45–55Hz |
| Voltage Accuracy | ±0.5% (Output Voltage Range: 200–1000V) | Display | 10.1-inch Capacitive Color Touchscreen |
| Current Accuracy | ±1% (20% Rated Output Current to Maximum Output Current) | Operating System | Android 8.1 |
| Low-Voltage Output Voltage | 12V | Protection Mechanisms | Overcurrent protection, short-circuit protection, undervoltage protection, overvoltage protection, and overtemperature protection. |
| Low-Voltage Output Current | 5A Max | ||
| High-Voltage Power Supply Voltage | 50–1000V | ||
